Descrizione prodotto
MAIN FEATURES:
- Working width: 1650 mm. and 2000 mm.
- Min. slitting width: 12 mm.
- Max. finished rolls diameter: from 90 mm. up to 300 mm. according to the I.D.
- Finished rolls inside diameter: 1” – 1 ½ “ – 2” – 3”
- Slitting systems: razor blades and with score knives
- Rewinding group for with 4 or 8 rewinding shafts.
- Automatic end-tab application
- Automatic transversal cut-off
- Automatic core Loader in line with the Slitter-Rewinder
- Rewinding shafts automatic loading and unloading
PRODUCTION:
- Cycle time for rolls of 50 m. = 31 sec. approx.
Cycle time depends on material
FITTINGS:
- Double-adhesive and silicone tabs for special laminated materials
- Systems for rolls positioning and conveyance to the Packaging Machines
- Other fittings according to the material to be converted
- Lyner recovery systems
OTHERS FITTINGS AND DEVICES ACCORDING TO THE MATERIALS
AND THE NEEDS OF THE CUSTOMER
